Specialized Ruby Sora X3 EU Metallicsvart/Silver
Visa storleksrekommendation.
Artikelnummer.
B0214-7344 (44)
Övriga art.nr.
B0214-7348 (48)
B0214-7351 (51)
B0214-7354 (54)
B0214-7357 (57)
Cykelbeskrivning
With a smooth SR Suntour fork featuring lockout, powerful Tektro mechanical disc brakes, and double-walled alloy wheels, the Hardrock SE is prepared for mountain trails and urban jungles.
>A1 Premium Aluminum 29er frame with ORE downtube for a lighter, more compliant and durable bike, with disc mounts for upgrading.
>80mm-travel SR Suntour fork with preload adjustment and size-specific spring rates means the suspension is dialed for your size.
>Specialized Fast Trak Sport tires use Adaptive Tread Technology for lower rolling resistance, but have plenty of grip for confidence on the trail.
>Tektro Novela mechanical disc brake offers dual pad angle adjustment and reliable stopping power in all weather conditions.
>Shimano 7-speed, 12-32 cassette offers gearing options for getting up to speed on the trail.
>Specialized Body Geometry Hardrock saddle has ample padding for comfort, and front/rear bumpers for durability.
Cykelspecifikationer
Vikt
Uppgift om vikt saknas
Ram
Specialized A1 Premium Aluminum, 29er Geometry, ORE downtube, externally relieved headtube, forged dropouts, reinforced disc mount, replaceable alloy derailleur hanger
SWAT (Storage, water, air and tools)
Stötdämpare bak
Gaffel eller ev. stötdämpare fram
SR Suntour SF13-XCT 29", coil/MCU spring, 1-1/8" steel steerer, preload adj., 28mm steel stanchions, disc only lowers, 80mm travel
Styrlager
1-1/8" threadless, loose ball
Styrstolpe eller ev. styrstam
Alloy, 4-bolt clamp, 10-degree rise, 25.4mm
Styre
Specialized flat bar, alloy, 640mm/660mm wide, 8-degree backsweep, 4-degree upsweep, 25.4mm
Handtag
Specialized Body Geometry XCT, Kraton w/ gel, 132mm
Bromsar fram
Tektro Novela, mechanical disc, dual pad angle adjustment, 160mm rotor
Bromsar bak
Tektro Novela, mechanical disc, dual pad angle adjustment, 160mm rotor
Bromshandtag
Shimano, included w/ shifter
Växelförare fram
Shimano Tourney, 7-speed, 34.9mm clamp, top-swing, dual-pull
Växelförare bak
Shimano Altus, 8-speed, SGS Cage
Växelreglage
Shimano ST-EF51, 7-speed trigger w/ integrated brake lever
Kassett eller ev. drev bak
Shimano, 7-speed, 12-32
Kedja
KMC X8
Vevparti
Alloy, 7/8-speed, square taper spindle
Vevparti utväxling
42/34/24, steel
Vevlager
Square taper, cartridge bearings, 68mm shell
Pedaler
Composite platform, w/ reflectors, 9/16"
Fälgar
HR Disc 29", alloy double-wall, disc, pin joint, 25mm, 36h
Nav fram
Disc, alloy, double-sealed, loose ball, steel axle, QR, 36h
Nav bak
Disc, alloy, double-sealed, loose ball, steel axle, steel cassette body, QR, 36h
Ekrar
Stainless, 14g (2.0mm)
Däck fram
Specialized Fast Trak Sport, 29x2.0", wire bead, 40TPI
Däck bak
Specialized Fast Trak Sport, 29x2.0", wire bead, 40TPI
Innerslang
Standard Schrader valve
Sadel
Specialized Body Geometry Hardrock, steel rails, 143mm
Sadelstolpe
Alloy, 2-bolt, micro-adjust, 12.5mm offset, 30.9mm, 350mm/400mm
Sadelstolpsklämma
Forged alloy, 34.9mm, QR, nylon washer
Övrigt
Chainstay protector, reflectors, clear coat, owner's manual
Ramgeometri
Frame size
15.5 17.5 19.0 21.0 23.0.
Bottom bracket drop
63.5mm 63.5mm 63.5mm 63.5mm 63.5mm.
Bottom bracket height
310mm 310mm 310mm 310mm 310mm.
Chainstay length
442mm 442mm 442mm 442mm 442mm.
Crank length
170mm 175mm 175mm 175mm 175mm.
Handlebar width
700mm 700mm 700mm 700mm 700mm.
Head tube angle
71° 71° 71° 71° 71°.
Head tube length
110mm 100mm 115mm 130mm 150mm.
Reach
400mm 412mm 430mm 450mm 464mm.
Seat tube angle actual
73° 72° 72° 72° 73°.
Seat tube angle effective
73° 73° 73° 73° 73°.
Seat tube length center to top
394mm 445mm 483mm 533mm 584mm.
Seatpost length
350mm 350mm 400mm 400mm 400mm.
Stack
615mm 625mm 639mm 653mm 672mm.
Standover height
760mm 796mm 825mm 859mm 896mm.
Stem length
60mm 80mm 80mm 80mm 90mm.
Top tube length actual
550mm 572mm 594mm 621mm 644mm.
Top tube length horizontal
576mm 603mm 625mm 650mm 670mm.
Wheel base
1064mm 1091mm 1114mm 1139mm 1160mm.
